Siemens SINUMERIK Series Function Manual

H1: Manual and handwheel travel
3.10 Start-up: Handwheels
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
205
Machine data Value Meaning
3rd handwheel in the NCK
MD11350 $MN_HANDWHEEL_SEGMENT[2] 5 Hardware segment: PROFIBUS
MD11351 $MN_HANDWHEEL_MODULE[2] 2 Reference to logical base address of the handwheel slot of
the 2nd MCP
MD11352 $MN_HANDWHEEL_INPUT[2] 1 1st handwheel in the handwheel slot
4th handwheel in the NCK
MD11350 $MN_HANDWHEEL_SEGMENT[3] 0 No handwheel parameterized
MD11351 $MN_HANDWHEEL_MODULE[3] 0 No handwheel parameterized
MD11352 $MN_HANDWHEEL_INPUT[3] 0 No handwheel parameterized
5th handwheel in the NCK
MD11350 $MN_HANDWHEEL_SEGMENT[4] 5 Hardware segment: PROFIBUS
MD11351 $MN_HANDWHEEL_MODULE[4] 6 Reference to logical base address of the handwheel slot of
the 3rd MCP
MD11352 $MN_HANDWHEEL_INPUT[4] 1 1st handwheel in the handwheel slot
6th handwheel in the NCK
MD11350 $MN_HANDWHEEL_SEGMENT[5] 5 Hardware segment: PROFIBUS
MD11351 $MN_HANDWHEEL_MODULE[5] 5 Reference to logical base address of the handwheel slot of
the 4th MCP
MD11352 $MN_HANDWHEEL_INPUT[5] 2 2nd handwheel in the handwheel slot
Logical base addresses:
Machine data Value Meaning
MD11353 $MN_HANDWHEEL_LOGIC_ADDRESS [0] 288 Logical base address handwheel slot 1st MCP
MD11353 $MN_HANDWHEEL_LOGIC_ADDRESS [1] 304 Logical base address handwheel slot 2nd MCP
MD11353 $MN_HANDWHEEL_LOGIC_ADDRESS [4] 330 Logical base address handwheel slot 4th MCP
MD11353 $MN_HANDWHEEL_LOGIC_ADDRESS [5] 320 Logical base address handwheel slot 3rd MCP
