Siemens SINUMERIK Series Function Manual

K5: Mode groups, channels, axis interchange
5.4 Axis/spindle replacement
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
331
Examples
The sequence of NC/PLC interface signals to change an NC axis to a PLC axis and to
transition an NC axis into a neutral axis by the PLC are shown in the following diagrams.




7LPH
$IWHUSRZHU21 
3/& !1&.'%%1&. !3/&'%%
1HZ7<3(3/&

Figure 5-7 Changing an NC axis to a PLC axis







1HZ7<3(3/&

7LPH
$IWHUSRZHU21
3/& !1&.'%%1&. !3/&'%%
1HZ7<3(3/&

Figure 5-8 Changing an NC axis to a neutral axis through the PLC
