W4: Grinding-specific tool offset and tool monitoring
17.1 Tool offset for grinding operations
Extended Functions
808 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
Tool parameter Meaning Bit in $TC_TPG2 Hex Dec
Wear tool length compensation
$TC_DP12 Length 1 11 0800 4096
$TC_DP13 Length 2 12 1000 8192
$TC_DP14 Length 3 13 2000 16384
$TC_DP15 Radius 14 4000 32768
$TC_DP16 Reserved 15 8000 65536
$TC_DP17 16 10000 131072
$TC_DP18 17 20000 262144
$TC_DP19 18 40000 524288
$TC_DP20 Reserved 19 80000 1048576
Tool base dimension / adapter dimension tool length compensation
$TC_DP21 Basic length 1 20 100000 2097152
$TC_DP22 Basic length 2 21 200000 4194304
$TC_DP23 Basic length 3 22 400000 8388608
Technology
$TC_DP24 Reserved 23 800000 16777216
$TC_DP25 Reserved 24 1000000 33554432
Example of parameter chain:
Lengths 1, 2 and 3 of the geometry, the length wear and the tool base / adapter dimensions
of lengths 1, 2 and 3 on a grinding tool (T1 in the example) must be automatically
transferred.
Furthermore, the same tool type applies to tool edges 1 and 2.
Tool type $TC_DP1 Bit 0
Length 1 $TC_DP3 Bit 2
Length 2 $TC_DP4 Bit 3
Length 3 $TC_DP5 Bit 4
Wear
Length 1 $TC_DP12 Bit 11
Length 2 $TC_DP13 Bit 12
Length 3 $TC_DP14 Bit 13
Base/adapter dimension
Length 1 $TC_DP21 Bit 20
Length 2 $TC_DP22 Bit 21
Length 3 $TC_DP23 Bit 22
