Z2: NC/PLC interface signals
18.3 Manual and Handwheel Travel (H1)
Extended Functions
870 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
DB21, ...
DBX40.7-6,
DBX46.7-6,
DBX52.7-6
Traversing command plus and minus for geometry axis (1, 2, 3)
Application
example(s)
Releasing the axis clamp when the traversing command is identified.
Note
For axes on which the clamping is not released until a drive command is detected, continuous-path
mode (
G64) is not possible.
Corresponding to ... DB21, ... DBX12.7 or DBX12.6 ff (traversing key plus and minus for geometry axis)
DB21, ... DBX 40, 46, 52 Bit 5 (traversing request plus/minus)
DB21, ...
DBX41.0-6,
DBX47.0-6,
DBX53.0-6
Active machine functions for geometry axis (1, 2, 3)
INC1, INC10, INC100, INC1000, INC10000, INCvar, continuous
Edge evaluation: No Signal(s) updated: Cyclically
Signal state 1 The corresponding machine function is active.
Bit 0 = 1 INC
Bit 1 = 10 INC
Bit 2 = 100 INC
Bit 3 = 1000 INC
Bit 4 = 10000 INC
Bit 5 = Var. INC
Bit 6 = continuous
The reaction to actuation of the traversing key or rotation of the handwheel varies, depending on
which machine function is active.
Signal state 0 The machine function in question is not active.
Corresponding to ... DB21, ... DBB13 bit 0-5 ff (machine function INC1, ... for geometry axis)
DB21, ... DBB13 bit 6 ff (machine function continuous for geometry axis)
DB21, ...
DBX43.0, 49.0, 55.0
Handwheel direction of rotation inversion active for geometry axis (1, 2, 3)
Edge evaluation: No Signal(s) updated: Cyclically
Signal state 1 The inversion of the handwheel direction of rotation is active for the geometry axis.
Signal state 0 The inversion of the handwheel direction of rotation is not active for the geometry axis.
Corresponding to ... DB31, ... DBX15.0, DBX19.0, DBX23.0.(invert handwheel direction of rotation for geometry axis)
