Z2: NC/PLC interface signals
18.3 Manual and Handwheel Travel (H1)
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
871
DB21, ...
DBX332.0-2,
DBX336.0-2,
DBX340.0-2
Handwheel active for orientation axis (1, 2, 3)
Edge evaluation: No Signal(s) updated: Cyclically
Feedback signal indicating which handwheel is active for the orientation axis.
The interface can be interpreted either bit or binary-coded. The specification is performed via:
MD11324 $MN_HANDWH_VDI_REPRESENTATION
Bit-coded: Maximum of three handwheels
Note
At any one time, the axis can only be assigned to one handwheel. If several interface signals are
set simultaneously, then the following priority applies: "Handwheel 1" before "handwheel 2" before
"handwheel 3"
Number of the assigned handwheel Bit 2 Bit 1 Bit 0
1 0 0 1
2 0 1 0
3 1 0 0
Binary-coded: Maximum of six handwheels
Number of the assigned handwheel Bit 2 Bit 1 Bit 0
1 0 0 1
2 0 1 0
3 0 1 1
4 1 0 0
5 1 0 1
Signal state 1
6 1 1 0
Signal state 0 A handwheel is not active for the orientation axis.
Corresponding to ... DB21, ... DBX332.0-2 ff (activate handwheel)
DB21, ...
DBX332.4-5,
DBX336.4-5,
DBX340.4-5
Plus and minus traversing request for orientation axis (1, 2, 3)
Edge evaluation: No Signal(s) updated: Cyclically
The signal is the same as the previous traversing command signal.
Signal state 1
• JOG mode:
With the plus or minus traversing key.
• REF mode:
With the traversing key that takes the axis to the reference point.
• AUTOMATIC/MDI mode:
A program block containing a coordinate value for the axis in question is executed.
