Terex MHL360 E - Page 243

CARE AND MAINTENANCE 7
MHL360 E 7.23
Item
Lubricating point
Quantity
daily
Weekly
Remarks
1*
Bearing of cab which can be raised and
moved forward
17
X
Automatic central lubrication,
uppercarriage
2
Boom bearing
2
X
3 Lift cylinder bearing 4 X
4
Dipperstick bearing
2
X
5
Dipperstick cylinder bearing
4
X
6
Slewing joint (slew ring, toothing)
8
X
7
Work attachment mounting bearing
2
X
Manual lubrication
8 Grab spherical plain bearing (option) 1 X
9
Cab door hinge, lock (see Fig. 272)
3
X
10
Engine hood hinge
2
X
11
Maintenance door hinge
2
X
12
Hinge on the cooler flap of the water/charge
air cooler
2
X
13
Hinge on the cooler flap of the hydraulic oil
cooler
2
14
Outrigger foot bearing
4
X
15
Outrigger leg bearing
4
X
16 Outrigger cylinder bearing (for outrigger leg) 4 X
17
Outrigger cylinder bearing (for undercarriage)
4
X
18
Steering housing bearing (see Fig. 269)
6
X
19
Steering cylinder bearing (see Fig. 270)
4
X
20
Oscillating axle bearing (see Fig. 271)
1
X
21 Grease nipple on cylinder bearings 8 X Perform additional lubrication
(manual lubrication) with loading
equipment lowered to the
ground (system not under pres-
sure).
ATTENTION
* The designated points must undergo a visual and functional inspection every 500 operating hours. Look
out for general damage and wear in particular.
h Chapter 7.6.4 Maintenance and inspection plan
Defective grease nipples may result in bearing damage. Replace damaged grease nipples immediately
and check if grease passes through. Following maintenance work, manually lubricate a lubricating
point until grease escapes
.
j WARNING
Danger of injury due to falling
• Before greasing the machine, apply the outriggers and lower the loading equipment (boom in hori-
zontal position).
• The grab must be lubricated separately as described in the operating instructions supplied with the
grab.
In an emergency: Administer first aid, seek treatment from a doctor
