5.15.3 fully applied
j WARNING
Danger of injury due to unse-
cured loading machine
• Before switching off the diesel
engine, engage the parking
brake.
• With the exception of emergency
braking, do not engage the park-
ing brake unless the machine is
stopped.
In an emergency: Administer first
aid, seek treatment from a doctor
Service brake
The service brake is used for braking during
travel. The lock is provided for temporary
standstill. The brake pressure diminishes after
the diesel engine has been turned off for
some time. Indicator (156/15) and the buzzer
indicate the status.
B SB508 60
Buzzer and indicator off: Brake pres-
sure sufficient
B SB508 76
n Buzzer and indicator on: Brake
pressure no longer sufficient
Apply parking brake or start diesel en-
gine.
►
Operate pedal (157/9). The braking effect
changes depending on the pedal travel.
Parking brake
Parking brake for parking the loading ma-
chine.
(157/63)
(156/23)
Parking brake
B SB507 58
B SB507 65
Not active
B SB507 59
B SB508 75
Engaged
►
Press parking brake button toggle
(157/54).
