Terex MHL360 E - Dimensions

3 TECHNICAL DATA
3.8 MHL360 E
3.3 Dimensions
3.3.1 Uppercarriage and undercarriage
331-1410-501360-0560-501
2 2 0
3310
3 5 0 0
2 8 7 0
1 5 7 0
5 0
1680
2940
4370
4800
30001960
3000
3200
5980
Fig. 14 Dimensions (measurements in mm) with 12.00-24 tires
