TECHNICAL DATA 3
MHL360 E 3.11
3.4 Technical data
Diesel engine
Manufacturer and model: Deutz TCD 7.8 L6 4V
Design: 6-cylinder in-line engine
Control: EEC IV
Method of operation: 4-stroke diesel, common
rail direct fuel injection, turbocharger, controlled
exhaust gas recirculation, diesel particle filter
with automatic regeneration
Engine output: 190 kW
Rated speed: 2000 rpm
Displacement: 7,8l
Cooling system: Coolant and charge air cool-
ing, with temperature controlled fan speed
Emission standard: III C / EPA IV interim
Specific fuel consumption: 209 g/kWh at
100% nominal output
Air filter type: Two-stage filter with safety valve
Electrical system
Nominal voltage: 24 V
Battery: 2x 12 V / 110 / 750 Ah / A (as per EN)
Generator: 28 V / 100 A
Starter: 24 V / 4.0 kW
Cold start auxiliary device: Heating flange
Lighting system:
1 x H3 headlamp at uppercarriage,
1 x H3 headlamp on cab floor,
Limiting and blinker lights
Optional additional working floodlights H3 or in
XENON.
Magnet system (optional): 20 kW or 30 kW DC
generator with control unit and induction monitor-
ing, driven directly by diesel engine via V-belts,
for operation of the magnetic plates.
HYDRAULIC SYSTEM
Main pump: Adjustable double displacement
pump in an open circuit, angular disk design with
load limit sensing control and flow on demand
control for working hydraulics, separate adjusta-
ble double displacement pump in a closed circuit
for the slewing movement of the uppercarriage.
Delivery rate: Max. 2x280 l/min and 2x140 l/min
at 2000 rpm
Working pressure: Max. 320 / 360 bar
Additional pumps: Gear pumps in the open cir-
cuit for supplying auxiliary loads.
Oil cooler: Fan speed thermostatically controlled.
Hydraulic oil filter: Return line filter, bypass flow
filter for working equipment optional. Pressure
filter for closed slewing circuit.
Loading equipment: Hose rupture safety valves
for lift cylinders, hose rupture safety valves for
dipperstick cylinders.
Travel drive
Variable speed axial piston motor with travel
brake valve. 2-speed manual transmission. 4-
wheel drive.
Travel speed:
1st gear: max 5 km/h
2nd gear: max 15 km/h
Gradeability: max. 30 %
Turning radius: 8.0 m
Rotary drive
Slewing ring with inner gear teeth. Drive via plane-
tary gears. Integrated multi-disk brake, electrically
activated.
Uppercarriage swing speed: 0 – 6 rpm
Swing range: 360° unrestricted
Max. torque: 91 kNm
