Chapter 7: PC SOFTWARE OFFLINE SETTINGS
10. ACTIVATION SETTING MODE
7-57
Step 2. From the setting Contents, select the control input's assigned function.
Step 3. After setting completion, click on the [Apply] button to save the settings and click on the [OK] button to
close the [Control Input Settings] window.
[Description of assignable functions]
No function set for the control input.None
Makes broadcasts according to the EV broadcast pattern set in the [Pattern
Settings] window.
EV Broadcast
Makes broadcasts according to the interrupt broadcast pattern set in the
[Pattern Settings] window.
Interrupt Broadcast
Makes broadcasts according to the base pattern set in the [Pattern Settings]
window.
Base Pattern Change
Clears the failure mode and exits the failure indication mode.
(Extinguishing all failure indicators and stopping the buzzer.)
Failure Output Reset
Enters emergency mode. It is also possible to recall and broadcast the pattern
set in the [Emergency Pattern Settings] window.
Emergency Activation
Receives failure input data from other system components and enables the
failure indicators of the RM-200XF, RM-200X, VX-2000 and VX-2000SF units.
Fault Display Input
Corrects the VX-2000's time to the nearest ±30 seconds.
(Example) If a control input is received at 00:05:45, the time is adjusted to
00:06:00.
If a control input enters at 00:05:15, the time is adjusted to 00:05:00.
Time Adjustment
Resets the emergency mode to general mode.Emergency Reset
Activates the control output set in the [Pattern Settings] window.Control Output Interlock
Selects one zone to be monitored.Audio Monitor
Changes the output volume relative to the volume pattern set in the [Pattern
Settings] window.
Changes can be made in steps of 3, 6, 9, 12, 15, 18 or 21 dB.
Volume Up/Down
If a failure is confirmed and a control input is activated, a Remote Microphone's
buzzer stops and the failure indicator changes from flashing to continuously
lit. A control output can be provided in synchronisation with the control input
activation. (When a failure corresponding to the pattern created in the [Failure
Output Pattern Settings] window takes place, Remote Microphone's the failure
indicator flashes and the buzzer sounds.)
Failure Output Receipt
Stops only base pattern broadcasts.Base Pattern Stop
Assigns the failure data from the external equipment to the Failure Output
Pattern.
External Fault CIN*
* Available when the VX-2000 Setting Software Version 2.1 or later is installed.
The EV message stops.Silence
