Chapter 2: PRODUCT DESCRIPTIONS
2. NOMENCLATURE AND FUNCTIONS
2-12
2.6. Remote Microphone Input Module VX-200XR
[Front] [Side]
1
1. Input connector
This RJ45 connector connects to the Link connector of the RM-200X or RM-200XF Remote Microphone.
The VX-200XR module is designed to be used with the RM-200X Remote Microphone or RM-200XF Fireman's
Microphone. Insert the module into the VX-2000's input module slot for each Remote or Fireman's Microphone
used in the system.
