Toa VX-2000SF - Remote Microphone Rm-200 X

Chapter 13: SPECIFICATIONS
2. SPECIFICATIONS
13-14
2.2. Remote Microphone RM-200X
* 0 dB = 1 V
Note: The design and specifications are subject to change without notice for improvement.
Power Source 24 V DC (operating range: 16 – 40 V DC), supplied from RJ45 connector
or power input jack (non-polarity type)
Usable power input plug: 5.5 mm outer diameter,2.1 mm inner diameter,
and 9.5 mm long
Current Consumption Under 200 mA (RM-200X), 750 mA (with 9 RM-210s connected)
Audio Output 0dB*,600Ω,balanced,RJ45connector
Gooseneck Microphone Unidirectional electret condenser microphone
External Microphone Input –40dB*,2.2kΩ,unbalanced,minijack,phantompowering
Distortion Under 1%
Frequency Response 100 Hz – 20 kHz
Signal to Noise Ratio Over 60 dB
Internal Monitor Speaker 200 mW
Volume Control Microphone volume control, Monitor speaker volume control
Number of Function Keys 15, extendable up to 105 (with 9 RM-210s connected)
Key Extension 10 keys extension per RM-210, EXTENSION connector
Number of Connectable Units 8 (include RM-200XF)
Communication System LONWORKS Twisted Pair Free Topology Transceiver
Connection Cable and Connector Category 5 STP cable, RJ45 connector
Communication Distance 500 m (free topology wiring)
Finish ABS resin, blueish gray (PANTONE 538 or its equivalent)
Dimensions 190 (w) x 76.5 (h) x 215 (d) mm (gooseneck microphone excluded)
Weight 850 g
