Toa VX-2000SF - VX-2000 Control Input Connections

Chapter 9: CONNECTIONS
6. CONNECTION CABLE PIN ASSIGNMENT
9-24
6.4. VX-2000 Control Input Connections
* Both Common terminals are factory-connected to the VX-2000's internal GND terminal.
Continued on next page
Connector Name RJ45 Pin No. Colour Pair Assignment
CTRL IN 1 – 8 Orange / white CTRL IN 1
Orange CTRL IN 2
Green / white CTRL IN 3
Blue CTRL IN 6
Blue / white CTRL IN 5
Green CTRL IN 4
Brown / white CTRL IN 7
Brown CTRL IN 8
Shield Shield CTRL IN 1 – 8 Common*
CTRL IN 9 – 16 Orange / white CTRL IN 9
Orange CTRL IN 10
Green / white CTRL IN 11
Blue CTRL IN 14
Blue / white CTRL IN 13
Green CTRL IN 12
Brown / white CTRL IN 15
Brown CTRL IN 16
Shield Shield CTRL IN 9 – 16 Common*
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
