Toa VX-2000SF - VX-200 SI Connections

Chapter 9: CONNECTIONS
6. CONNECTION CABLE PIN ASSIGNMENT
9-30
6.6. VX-200SI Connections
Continued on next page
Connector Name RJ45 Pin No. Colour Pair Assignment
CTRL IN 1 – 4 Orange / white CTRL IN 1
Orange COM 1
Green / white CTRL IN 2
Blue COM 3
Blue / white CTRL IN 3
Green COM 2
Brown / white CTRL IN 4
Brown COM 4
Shield Shield NC
CTRL IN 5 – 8 Orange / white CTRL IN 5
Orange COM 5
Green / white CTRL IN 6
Blue COM 7
Blue / white CTRL IN 7
Green COM 6
Brown / white CTRL IN 8
Brown COM 8
Shield Shield NC
CTRL IN 9 – 12 Orange / white CTRL IN 9
Orange COM 9
Green / white CTRL IN 10
Blue CO M 11
Blue / white CTRL IN 11
Green COM 10
Brown / white CTRL IN 12
Brown COM 12
Shield Shield NC
CTRL IN 13 – 16 Orange / white CTRL IN 13
Orange COM 13
Green / white CTRL IN 14
Blue COM 15
Blue / white CTRL IN 15
Green COM 14
Brown / white CTRL IN 16
Brown COM 16
Shield Shield NC
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
