Chapter 13: SPECIFICATIONS
2. SPECIFICATIONS
13-30
2.22. Wall Mounting Bracket WB-RM200
Finish
Surface treated steel plate, black, paint
Weight
100 g
Set Composition
Mount bracket ...... 1
Usable Unit
RM-200X, RM-200M, RM-210
•Accessories
Self-tapping screw (4 x 25) ........................ 2
Machine screw M3.5 x 20 ......................... 2
Note: The design and specifications are subject to change without notice for improvement.
2.21. Power Amplifier Input Module VP-200VX
Power Source Supplied from VP-2064, VP-2122, VP-2241, VP-2421
Current Consumption Under 30 mA
Power Amplifier Link RJ45 female connector for connecting the VX-200SP or VX-200SZ Audio
output module
Twisted-pair straight cable (TIA/EIA-568A standard)
Finish Panel: Surface-treated steel plate
Dimensions 88 (w) x 25.8 (h) x 73.2 (d) mm
Weight 50 g
Applicable Model VP-2064, VP-2122, VP-2241, VP-2421
* 0 dB = 1 V
Note: The design and specifications are subject to change without notice for improvement.
