Toa VX-2000SF - Initial Impedance Settings

Chapter 10: PC ONLINE CHECKS AND ADJUSTMENTS
3. SYSTEM CHECK FUNCTIONS
10-10
3.2. Initial Impedance Settings
Notes
•The VX-200SZ Impedance Detection Module monitors speaker line impedance to detect shorts or open
circuits in the lines. An initial impedance value is used as a reference to detect speaker line irregularities.
•Speakerlineimpedancetendstochangeovertime,thusincreasinganyvariationfromtheinitialimpedance
value set at the time of installation, and possibly causing the VX-200SZ to detect a line failure even when the
speaker line is functioning correctly. Especially during the first several months after installation, it is highly
recommended that the reference impedance be monthly updated using the initial impedance setting procedure.
Since then, be sure to periodically update the reference impedance at the time of routine maintenance.
The initial impedance setting determines the VX-200SZ's initial impedance value.
The following methods can be used to set the initial impedance.
* This function applies to the VX-2000 Setting Software Version 2.0 or later.
Sections Operated
PC Software
Menu Selection
Connection check*
Initial Impedance Settings
VX-2000SF Initial Setting Switch
(Refer to .)
Features
•Initial impedance settings can be simultaneously
performed for all VX-200SZ modules in the system.
•Connection checks are made after initial impedance
settings completion.
•Settings can be simultaneously performed for all
VX-200SZ modules in the system.
•Only the initial impedance settings are performed
(no connection checks are made).
•Enables the initial impedance settings for individual
VX-2000SF units.
•Does not need to be operated from a PC.
Use this function when further checking
connections after initial impedanc e
settings at the time of initial installation.
Refer to .
Use this function only when setting the
VX-200SZ' s initial impedanc e value
during periodic maintenance.
Refer to .
p. 10 -13
p. 10 -11
p. 10 -12
