Toa VX-2000SF - Surveillance Frame VX-2000 Sf

Chapter 13: SPECIFICATIONS
1. BLOCK DIAGRAM
13-6
1.6. Surveillance Frame VX-2000SF
[AUDIO LINK IN]
[AUDIO LINK OUT]
Standby Amplifier Link Connector
[STANDBY PA LINK]
Audio Signal Bus Connector
Overheart Status Input
DC Fuse Blowout Detection Input
Standby Control Output
Audio Signal Output (balanced)
Audio Monitor Output (balanced)
SETTING DIP SW
8 7 6 5 4 3 2 1
Unit ID number setting Terminator ON/OFF not use
BPF BPF
LPF
OSC 40 kHz OSC 20 kHz OSC 40 Hz
FAULT
RUN
RESET
INIT SET
LON
DS-SF Link Connector
[DS-SF LINK 1] [DS-SF LINK 2]
Data Link Connector [DATA LINK]
LA
Same as above
Audio Bus 1
Slot 1
Audio Bus 2 Audio Bus 3 Audio Bus 4 Pilot Tone Bus 1 (40 kHz)
Pilot Tone Bus 2 (20 kHz)
Pilot Tone Monitor Bus 2 (40 kHz)
Pilot Tone Monitor Bus 1 (20 KHz)
Pilot Tone Bus 3 (40 Hz)
Audio Monitor Bus Standby Amplifier Bus
Slot 2 – 10
OPTION
RS-485 Driver
LONWORKS
CPU
Filter
Detection Circuit
40 kHz
Filter
Detection Circuit
20 kHz
LA
DC Power Input [DC POWER IN]
POWER
Fuse 7.5 A
