Toa VX-2000SF - Control Input

Chapter 4: FUNCTIONS
3. ACTIVATION ITEMS
4-13
3.2. Control Input
Broadcast or control patterns can be recalled by way of external control signals.
Functions that can be activated by way of the control input terminal are as follows:
[Table of functions that can be assigned to the control input]
*
1
Activated at the time of system power-on when the corresponding control input is set ON.
*
2
Available when the VX-2000 Setting Software Version 2.1 or later is installed.
Notes
• TheVX-2000isequippedwith16controlinputterminals.Thenumberofcontrolinputscanbeincreasedby
adding the VX-200SI Control Input Module to the VX-2000SF. The number of control inputs can be increased
by 16 terminals per VX-200SI up to a total of 128 terminals per system.
• BecauseboththeVX-2000'scontrolinputandVX-200SIemployphotocouplers,theycanbeinsulatedthrough
modification. For the modification procedures, refer to
p. 8-17 (VX-2000) or p. 8-32 (VX-200SI).
• TheVX-200SI'scontrolinputsarefactory-presettobeactivatedbya"make"signal.Thiscanbechangedto
"break" signal activation by way of the DIP switch on the circuit board. For the switching procedures, refer to
p. 8-31.
Activation Item Function
Emergency Activation*
1
Activates Emergency mode. Recalls assigned emergency broadcast
patterns for broadcast.
Silence*
2
The EV message stops.
Emergency Reset Restores the general-purpose broadcast mode.(Reset EV messages
cannot be assigned.)
Interrupt Broadcast Pattern*
1
Recalls assigned Interrupt broadcast patterns for broadcast.
EV Message Broadcast Pattern*
1
Recalls assigned EV message broadcast patterns for broadcast.
Base Pattern Change*
1
Recalls assigned base patterns for broadcast.
Base Pattern End Stops BGM broadcasts.
Control Output Interlock*
1
Recalls assigned control output interlock patterns to activate the control
output.
Audio Monitoring*
1
Selects the desired zones to monitor from the VX-2000 monitor output.
Volume UP Operation*
1
Changes the assigned volume level in relative steps of 3, 6, 9, 12, 15,
18,or 21 dB.
Volume DOWN Operation*
1
Failure Output Reception*
1
Transmittingacontrolsignalafterconrmingtheoccurrenceofafailure
terminates the Remote Microphone buzzer. The failure detection indicator
switchesfromashingtosteady-onstatus.Thecontroloutputactivatedin
synchronisation with failure detection can be set.
Failure Output Reset Resets the failure detection indication.
Clock Adjustment*
1
Corrects the VX-2000 internal timer setting to the nearest 30 seconds.
[Example]
If a control signal is received at 00:05:45, the time is adjusted to 00:06:00.
If a control signal is received at 00:05:15, the time is adjusted to 00:05:00.
Failure Display Input*
1
If failure data is received from other system, the failure indicators of the
RM-200XF, RM-200X, VX-2000 and VX-2000SF light. Such event is
recorded in a log.
External Fault CIN*
2
Assigns the failure data from the external equipment to the Failure Output
Pattern.
