Chapter 13: SPECIFICATIONS
2. SPECIFICATIONS
13-16
2.4. System Manager VX-2000
•Optionalproducts
Voice announcement board: EV-200
Isolation transformer: IT-450 (audio link output)
•Accessories
Rack mount bracket (preinstalled on the unit) .......................... 2
Rack mounting screw (5 x 12) .................................................. 4
Fiber washer ............................................................................. 4
Blank panel ............................................................................... 7
Blank panel mounting screw .................................................. 14
Setting software installation CD ............................................... 1
Fuse (T1.6 A L) ......................................................................... 1
Fuse (T6.3 A L) ......................................................................... 1
Power Source 24 V DC (operating range: 20 – 40 V DC)
M3.5 screw terminal, distance between barriers: 8.8 mm
Current Consumption Under 650 mA (20 V DC)
Input –20 dB*, unbalanced, Number of module slots: 8
Usable Input Module VX-200XR, VX-200XI, 900 series plug-in modules (M-01F, M-01M, M-01P,
M-01S, M-01T, M-03P, M-51F, M-51S, M-51T, M-61F, M-61S, M-61T, U-01F,
U-01P, U-01R, U-01S, U-01T, U-03R, U-03S, U-61S, U-61T)
Audio Link Output Number of audio buses: 4
0 dB*, electronically balanced, RJ45 female connector
Twisted-pair straight cable (TIA/EIA-568A standard)
Monitor Output 0 dB*, electronically balanced, XLR receptacle (3 pins)
Frequency Response 20 Hz – 20 kHz
Signal to Noise Ratio Over 60 dB
Distortion Under 0.5%
Cross Talk Under –60 dB (1 kHz, 0 dB*)
Control Input 16 inputs, no-voltage make contact, open voltage: 17 V DC,
short circuit current: Under 5 mA, RJ45 connector x 2
Control Output 16 outputs, open collector output, withstand voltage: 30 V DC,
control current: Under 5 mA, RJ45 connector x 2
Chime Tone Built-in chime: 4-tone chime (up) / 4-tone chime (down) / 2-tone chime / Gong
Communication System PC (Setting software to be installed): D-sub connector (9 pins), cross cable,
RS-232C
VX-2000SF: RJ45 female connector,
Twisted-pair straight cable (TIA/EIA-568A standard),
LONWORKS RS-485
Operating Temperature 0 to +40°C
Finish Panel: Surface-treated steel plate, black (30% glossy), paint
Dimensions 482 (w) x 132.6 (h) x 337 (d) mm
Weight 6.4 kg
* 0 dB = 1 V
Note: The design and specifications are subject to change without notice for improvement.
