Toa VX-2000SF - Remote Microphone Extension

Chapter 13: SPECIFICATIONS
2. SPECIFICATIONS
13-15
2.3. Remote Microphone Extension RM-210
•Accessories
Extension cable ......................................... 1
Linkage bracket A ...................................... 2
Linkage bracket B ...................................... 1
Screw for linkage bracket ........................ 12
Note: The design and specifications are subject to change without notice for improvement.
Current Consumption 20mAmax.(intermsofRM-200M’sDCpowerinput)
75 mA max. (in terms of DC power inputs of RM-200X and RM-200XF)
Connection Connection to RM-200M, RM-200X or RM-200XF by way of dedicated cable
Number of Function Keys 10
Function When used to expand the RM-200M:
Selects and activates the Voice Announcement Board messages.
When used to expand the RM-200X and RM-200XF (PC software setting):
Emergency activation, Emergency reset, BGM pattern selection,
EV message activation, Broadcast zone selection,
Monitor zone selection, Chime activation, Talk key activation,
Control output activation, Input volume adjustment,
Zone volume adjustment, and Failure output indication and Reset.
Finish ABS resin, blueish gray (PANTONE 538 or its equivalent)
Dimensions 110 (w) x 76.5 (h) x 215 (d) mm
Weight 350 g
