Toa VX-2000SF - Maximum System Configuration Table

Chapter 2: PRODUCT DESCRIPTIONS
1. MAXIMUM SYSTEM EXAMPLE
2-3
1.2. Maximum System Configuration Table
Component
Input Source Equipment
Maximum No. of Units
RM-200XF
RM-200X
EV-200
Chime (internal)
Paging Microphone and Music
Sources (Cassette, CD, etc.)
4 units
4 units ("Emergency" type)
8 units ("General" type)
2 units
1 unit
8 units
8 units in total
of both models
18 units in total of
all Input Source
Equipment
RM-200XF's and RM-200X's Function Key Extension
RM-210 10 units (115 function keys) per RM-200XF
9 units (115 function keys) per RM-200X
315 function keys per system
VX-2000
VX-2000 1 unit
VX-2000SF
VX-2000SF 8 units*
Input Module (to be installed in VX-2000)
VX-200XR
VX-200XI
900 module
8 units in total of all Input Modules
Usable 900 modules: M-01F, M-01M, M-01P, M-01S, M-01T, M-03P, M-51F,
M-51S, M-51T, M-61F, M-61S, M-61T, U-01F, U-01P,
U-01R, U-01S, U-01T, U-03R, U-03S, U-61S, and U-61T
SF Module (to be installed in VX-2000SF)
VX-200SP, VX-200SP-2 80 units
VX-200SZ, VX-200SZ-2 80 units
VX-200SI 7 units
VX-200SO 7 units
80 units in total of all SF Modules
(10 units per VX-2000SF)
Optional Equaliser Card (to be installed in VX-200SP, VX-200SP-2, VX-200SZ and VX-200SZ-2)
VX-200SE 80 units
Control Input
VX-2000
VX-200SI
16 inputs
(as standard equipment)
112 inputs (7 units)
128 inputs in total
Control Output
VX-2000
VX-200SO
16 outputs
(as standard equipment)
112 outputs (7 units)
128 outputs in total
Power Amplifier
VP-2064 (4 ch)
VP-2122 (2 ch)
VP-2241 (1 ch)
VP-2421 (1 ch)
80 channels* (80 zones)*
Standby Amplifier 8 channels* (1 channel per VX-2000SF)
Note: The number and type of power amplifiers should be determined depending
on the required speaker output for each zone.
Note: Necessary power capacity should be calculated based on total system
specifications.
Power Amplifier Input Module
VP-200VX 88 units* in total of modules installed in Power and Standby Amplifiers
Power Supply
VX-2000DS 16 units* 2 units per VX-2000SF
VX-200PS 48 units* 3 units per VX-2000DS
Battery 32 or 64 units*
2 or 4 units per VX-2000DS
4 units in total of
Emergency-set models
* Available when the label on each packing box of the VX-2000 system components (VX-2000, VX-2000SF,
RM-200X, and RM-200XF) indicates "EN80," and the Setting Software Version is 3.0 or later.
