Toa VX-2000SF - 4. CONNECTIONS BETWEEN VX-2000 SF AND STANDBY AMPLIFIER

Chapter 9: CONNECTIONS
4. CONNECTIONS BETWEEN VX-2000SF AND STANDBY AMPLIFIER
9-9
4. CONNECTIONS BETWEEN VX-2000SF AND STANDBY AMPLIFIER
28 V 4.8 A
DC POWER IN
PA OUT (SP LINE)
PA LINK
CH
DC POWER IN
STANDBY
PA LINK
From VX-2000DS'
or VX-3000DS'
DC POWER OUT
RJ45 male connector
[VP-2241 Rear]
VP-200VX
Cat. 5 STP
RedBlack
VX-200SZ VX-200SP
VX-200SO
VX-200SI
[VX-2000SF Rear]
From VX-2000DS'
or VX-3000DS'
DC POWER OUT
Standby Amp. cable (supplied with the VX-2000SF)
Unused
Be sure to connect between all
STANDBY PA BUS connectors
as shown above.
[When VP-2241 is used]
