Chapter 13: SPECIFICATIONS
2. SPECIFICATIONS
13-13
2. SPECIFICATIONS
2.1. Fireman's Microphone RM-200XF
* 0 dB = 1 V
Note: The design and specifications are subject to change without notice for improvement.
•Accessories
Plug-in screw terminal ............................... 1
Wall mounting bracket ............................... 1
Wall mounting screw ................................. 2
Box mounting screw .................................. 2
Power Source 24 V DC (operating range: 16 – 40 V DC)
Current Consumption Under 200 mA (RM-200XF), 850 mA (with 10 RM-210s connected)
Audio Output 0dB*,600Ω,balanced
Hand-Held Microphone Dynamic microphone, Function switch (default: Press-to-talk),
Microphone element fault detection
Distortion Under 1%
Frequency Response 200 Hz – 15 kHz
Signal to Noise Ratio Over 55 dB
Internal Monitor Speaker 200 mW
Volume Control Microphone volume control, Monitor speaker volume control
Number of Function Keys 5(includingHand-heldmicrophone’sswitch),
extendable up to 105 (with 10 RM-210s connected)
Key Extension 10 keys extension per RM-210, EXTENSION connector
Number of Connectable Units 4
Communication System LONWORKS Twisted Pair Free Topology Transceiver
Connection Cable and Connector Category 5 STP cable, plug-in screw connector
Communication Distance 500 m (free topology wiring)
Finish ABS resin, blueish gray (PANTONE 538 or its equivalent)
Dimensions 200 (w) x 215 (h) x 82.5 (d) mm (excluding the coiled cord)
Weight 1.2 kg
Applicable Box YC-301, YS-11A
