Chapter 8: INSTALLATION AND SETTING PROCEDURES (HARDWARE)
1. RM-200XF AND RM-200X MICROPHONES
8-14
1.7. Creating Remote Microphone Name Labels
Using the VX-2000 System Setting Software function, assigned names of preset RM-200XF, RM-200X, and
RM-210 Function keys can be printed out. Once printed, cut out the printed names with scissors to use them as
corresponding name labels. The paper used for the name label must be under 0.2 mm in thickness.
[Inserting the name label]
• Fully insert the name label cut to the instructed size into the label entry slit.
• To remove the label, pull it out of the slit using the tip of knife blade.
[Example of printed out RM-200XF name label]
FIREMAN'S MICROPHONE
RM-200XF
MICSP CPU
OFF ON
[RM-200XF]
Name label
Name label entry slit
Power
Fault
CPU OFF
Emergency
Rest
Evacuation
EV
All Zones
Talk
