Toa VX-2000SF - Voice Announcement Board EV-200 M; Remote Microphone Input Module VX-200 Xr

Chapter 13: SPECIFICATIONS
2. SPECIFICATIONS
13-17
2.5. Voice Announcement Board EV-200M
* 0 dB = 1 V
Notes
•Use the CompactFlash card adapter on the market for recording by the EV-350R.
•Thedesignandspecificationsaresubjecttochangewithoutnoticeforimprovement.
•Accessories
Mounting screw .................................................................. 2
CompactFlash card (128 MB, preinstalled on the unit) ...... 1
Power Source 24 V DC, 0.2 A
Power Consumption 5 W
Output 0 dB*
Frequency Response 20 Hz – 20 kHz (44.1 kHz sampling)
20 Hz – 14 kHz (32 kHz sampling)
Distortion Under 0.3% (44.1 kHz, recording method: Extremely High)
Playback Mode Single source playback
No. of Playback Program 8 programs
Operating Temperature 0 to +50°C
Operating Humidity Under 90% (no condensation)
Dimensions 120 (w) x 18.6 (h) x 121 (d) mm
Weight 120 g
2.6. Remote Microphone Input Module VX-200XR
Power Source Supplied from VX-2000
Current Consumption Under 17 mA
Connectable Remote Microphone RM-200X and RM-200XF
Input Connector RJ45 female connector
Twisted-pair straight cable (TIA/EIA-568A standard)
Finish Panel: Aluminum, hairline
Dimensions 35 (w) x 78 (h) x 88 (d) mm
Weight 70 g
Applicable Model VX-2000
•Accessories
Mounting screw ......................................... 2
Note: The design and specifications are subject to change without notice for improvement.
