Chapter 3: SYSTEM OPERATION OUTLINE
5. EXTERNAL ATTENUATOR CONTROL TERMINAL OPERATION
3-8
5.2. Operation During Monitoring
[VX-200SZ]
Because the VX-200SZ monitors speaker lines by comparing their impedance, when external attenuators are
used, they are bypassed to monitor the system. When connecting an external attenuator to the VX-200SZ, set
as "Use external attenuator" in the PC software, then set the monitoring time interval.
Monitoring time intervals and External Attenuator Control terminal operations differ depending on the operation
mode and whether or not external attenuators are used.
*
1
PC Setting : Impedance Monitoring Interval Setting
*
2
PC Setting : Monitor Interval in AC Failure Mode
Note
When external attenuators are used, they are bypassed at set monitoring time intervals, even during BGM
broadcasts.
[VX-200SP]
Because the VX-200SP monitors speaker lines by checking with a pilot tone, external attenuators need not be
bypassed during monitoring. In this case, the Attenuator Control terminals do not operate during monitoring.
The VX-200SP carries out monitoring at intervals that correspond to the operation mode. For details, refer to
the table below.
Operation Mode
Monitoring Intervals Control Terminal Operation during Monitoring
Normal or Emergency Within 100 seconds Not work
Economy 24 hours
AC Failure Set by the PC setting*
3
*
3
PC Setting : Monitor Interval in AC Failure Mode
Operation Mode External Attenuator Monitoring Intervals Control Terminal Operation during Monitoring
Normal or Unused Within 100 seconds Not work
Emergency Used Set by the PC setting*
1
Bypasses external attenuators.
Economy Unused 24 hours Not work
Used Set by the PC setting*
1
Bypasses external attenuators.
AC Failure Unused Set by the PC setting*
2
Not work
Used Set by the PC setting*
2
Bypasses external attenuators.
