Chapter 5: OPERATION
2. EMERGENCY BROADCASTS
5-8
StairsStaff area
Guest rooms3F
Corridor3F
Guest rooms2F
Corridor2F
Hallway1F
LobbyGF
Staff areaGF
Entrance
Reception
Restaurant
Security
room
VX-2000
VX-2000SF
Amp.
Fireman's
Microphone
Conference room1F
2.2. Single-Origin EV Message Broadcast (Sequential Operation)
Here, explanations are given to the system in a hotel as an example.
[Internal wiring]
Speaker arrangements and their wiring in Building are as shown in the figure below.
