Chapter 4: FUNCTIONS
3. ACTIVATION ITEMS
4-14
Function
Recalls and broadcasts assigned Interrupt broadcast patterns during the
duration between set start and end times.
Recalls and broadcasts assigned EV broadcast patterns at set times.
Recalls and broadcasts assigned base patterns at set times.
Stops BGM play at set times.
Outputs assigned control output patterns during the duration between set
start and end times.
Increases the broadcast volume above the assigned pattern level during
the duration between set start and end times. The volume can be increased
by 3, 6, 9, 12, 15, 18 or 21 dB.
Decreases the broadcast volume below the assigned pattern level during
the duration between set start and end times. The volume can be decreased
by 3, 6, 9, 12, 15, 18 or 21 dB.
[Events that can be programmed into the timer]
[Day program setting example]
3.3. Internal Timer
The VX-2000 has an internal timer that enables base patterns to be changed and EV message broadcasts to
be made at preset times. Use the PC software to set the timer. For the timer settings, refer to p. 7-58.
Event
Interrupt broadcast
EV message broadcast
Base pattern change
Base pattern end
Control output interlocking
Volume UP operation
Volume DOWN operation
3.3.1. Preparing day programs
• DayProgramsarebasicoperatingprograms.Upto32eventscanbesetin1-minuteunitsperday(24hours)
for each program. Up to 10 Day Programs can be created.
• Eventsincluderecalledbroadcast/controlpatterns,orsetfunctionsactivatedatpresettimesorconcurrently
during a duration. The following table shows the events that can be programmed into the timer.
Event Number
Pattern Names Assigned to EventsEventEvent Start / End Times
