Chapter 4: FUNCTIONS
2. PATTERNS
4-4
2.2. Control/General-Purpose Broadcast Patterns
Use the PC software to create the desired patterns. For details, refer to
p. 7-45.
Notes
Interrupt and EV broadcast patterns can be simultaneously recalled. When simultaneously recalled, the system
operates as follows:
[Interrupt Broadcast]
•Iftheassigned input sources arethesame,broadcastsaremadetoeveryoutputzonesetin all recalled
patterns.
•Iftheassigned input sources aredifferent,buttherecalledpatternoutput zonesareduplicated,theinput
source assigned the highest priority is broadcast to all duplicated zones, while other recalled sources are
broadcast to the corresponding output zones that are not among the duplicated zones.
* Available when the VX-2000 Setting Software Version 3.0 or later is installed.
Pattern Type Feature
Control output pattern
•Allowstooutputcontrolsignalstoexternalequipment.Thecontrol output
is shorted by activation from a remote microphone or a control input. It
can also remain shorted for a period of time set by the internal timer.
•Oneormorecontroloutputsareset.
•Upto50patternscanbecreated.
Interrupt broadcast pattern
•AllowsthebroadcasthigherthanBGMinpriority.Interruptbroadcastcan
be made by activation from a control input. It can also be made continue
for a period of time set by the internal timer.
•Input sound sources including BGM sources, and their corresponding
output zones are set.
•Upto50patternscanbecreated.
•Oneormorecontroloutputsactivatedinsynchronisationwiththepattern
can be set.
EV broadcast pattern
•Allows broadcasts of EV messages from the EV-200 mounted in the
VX-2000. EV messages are recalled and broadcast by activation from
acontrol input. They can also be broadcast at a set time determined by
the internal timer.
•Includesgeneral-purposeEVmessagesandtheircorrespondingoutput
zones.
•Upto20patternscanbecreated.
•Oneormorecontroloutputsactivatedinsynchronisationwiththepattern
can be set. The control output is shorted during the duration of the EV
message broadcast.
Base pattern
•Allows BGM broadcast. BGM broadcast can be made by remote
microphone operation or a control input operation. It can also be made at
a set time determined by the internal timer.
•IncludesBGMsourcesandcorrespondingoutputzones.
•Upto20patterns*canbecreated.
•Oneormorecontroloutputsactivatedinsynchronisationwiththepattern
can be set.
Volume pattern
•Allowstocontrolaninputsensitivityoroutputzonevolume.Thevolume
can be controlled by activation from a remote microphone or a control
input. It can also remain changed for a period of time set by the internal
timer.
•Input:ThispatternincludesindividualinputsourcesexcludingRemote
Microphones.
•Output:Inthispattern,oneormoreoutputzonesareset.
•Atotalofupto156patternscanbecreatedforboththeinputandoutput.
