Toa VX-2000SF - Power Amplifier 4 X 60 W VP-2064

Chapter 13: SPECIFICATIONS
1. BLOCK DIAGRAM
13 -11
1.12. Power Amplifier 4 x 60 W VP-2064
Audio Signal Input
Input Module Slot
Audio Monitor Output
Standby Control Input
Green LED Control
Overheat Status Output
Red LED Control
DC Fuse Blowout
Detection Output
Cooling FanOverheat LED [OVERHEAT]
Control Circuit
Control Circuit
Power LED [POWER]
Fuse 7.5 A
DC
100 V
70 V
50 V
DC Power Input
[DC POWER IN]
CH1 Speaker Line Output
[PA OUT (SP LINE)]
HOT
COLD
CH2 Speaker Line Output
[PA OUT (SP LINE)]
HOT
COLD
DC Output
CH1
CH2
Same as above
CH3 Speaker Line Output
[PA OUT (SP LINE)]
HOT
COLD
CH3
Same as above
CH4 Speaker Line Output
[PA OUT (SP LINE)]
HOT
COLD
CH4
Same as above
