Chapter 13: SPECIFICATIONS
2. SPECIFICATIONS
13-21
2.10. Impedance Detection Module VX-200SZ
Power Source
Supplie
d from VX-2000SF
Current Consumption Under 150 mA
Power Amplifier Link RJ45 female connector for connecting the VP-2000 series or VP-3000 series
Power Amplifier.
Twisted-pair straight cable (TIA/EIA-568A standard)
External Attenuator
Control Output
Plug-in screw connector, relay, no-voltage make contact output,
transfer type, withstand voltage: 30 V DC, 250 V AC,
contact current: Under 7 A (DC), under 7 A (AC)
Applicable cable diameter: AWG 16 – AWG 24
Speaker Output Plug-in screw connector
Applicable cable diameter: AWG 16 – AWG 24
Power Amplifier Input Plug-in screw connector for connecting the VP-2000 series or VP-3000 series
Power Amplifier
Applicable cable diameter: AWG 16 – AWG 24
Fault Detection System Short circuit, open circuit (impedance detection method), ground fault
Finish Panel: Surface-treated steel plate
Dimensions 30.5 (w) x 132.6 (h) x 290.3 (d) mm
Weight 320 g
Applicable Model VX-2000SF
•Optionalproduct
Equaliser card: VX-200SE
•Accessory
Plug-in screw terminal ............................... 1
Note: The design and specifications are subject to change without notice for improvement.
