Chapter 9: CONNECTIONS
1. VX-2000 CONNECTIONS TO REMOTE MICROPHONES AND INPUT SOURCE EQUIPMENT
9-2
LINK
MONITOR OUT
DC POWER IN
8765 4321
CTRL IN
CTRL OUT
XLR type female connector
RCA plug
RJ45 male connector
Cat. 5 STP*
Cat. 5 STP*
[RM-200XF Bottom]
Cat. 5 STP* Cat. 5 STP*
Cat. 5 STP*
VX-200XIU-03R
VX-200XR
Base Pattern change and
Failure Output Receipt switches
AC230 V, 50/60 Hz
From VX-2000DS'
or VX-3000DS'
DC POWER OUT
To the next
Remote Microphone
To the next
Remote Microphone
Monitor Speaker and Zone selector
PM-660D
CD Player
AC Adaptor
Remote unit
[VX-2000 Rear]
[RM-200X Rear]
Failure Output indicators
Power
Amplifier
RU-2002
* TIA/EIA-568A standard Category 5 Shielded Twisted-Pair cable
(Abbreviated to "Cat. 5 STP cable.")
1. VX-2000 CONNECTIONS TO REMOTE MICROPHONES AND INPUT
SOURCE EQUIPMENT
To Next Page
