3. ACTIVATION ITEMS
4-8
3.1.2. Base pattern change
The base pattern assigned to the key is recalled for broadcast.
3.1.3. Base pattern end
BGM broadcasts stop.
Unused
Base Pattern key
Base Pattern Status LED
• Base pattern in use: Lights green.
• Base pattern not in use: OFF
Unused
Base Pattern End key
Base pattern not in use: Lights green.
3.1.4. Control output interlock
The assigned control pattern is recalled and the control output terminal is closed while the key is pressed.
Unused In progress: Lights green.
Control Output Pattern key
3.1.5. Audio monitoring
Individual zones can be set for monitoring. Pressing the key permits the current broadcast in the set zone to be
monitored by way of the Remote Microphone monitor speaker for 10 seconds.
Unused
Audio Monitor key
Monitor LED
• Audio monitoring in progress: Lights green.
• No audio monitoring executed: OFF
