Toa VX-2000SF - Page 228

Chapter 9: CONNECTIONS
3. SF MODULES (VX-200SP, VX-200SZ, VX-200SI, VX-200SO) CONNECTIONS
9-6
[When VP-3304 is used] (In the case shielded cables are used)
SP OUT
PA IN
PA LINK
H
C
H
C
SP OUT
PA IN
PA LINK
H
C
H
C
LINE MONITOR
H
C
VX-200SZ
VX-200SP
Cat. 5 STP
Cat. 5 STP
End of line
[VP-3304 Rear]
Amplifier output terminal
PA LINK
VOL.
RJ45 male connector
From VX-3000DS'
DC POWER OUT
1
1 n
n
HCHCHCHC E
CH4 CH3 CH2 CH1
PA OUT (SP LINE)
Shielded cable
Shield
Shield
Shielded
cables
Note: Be sure to connect the shield wire of each shielded cable to
the VP-3304's "E" terminal.
