Chapter 2: PRODUCT DESCRIPTIONS
2. NOMENCLATURE AND FUNCTIONS
2-9
2.4. System Manager VX-2000
RUN FAULT POWER
RESETSETTINGS
RS-232C
SUMMER
TIME
PC
SETTING
DAYLIGHT SAVING
SERVICE
SF
SERVICE ATA FLASH CARD
COMPACTFLASH CARD
COMPACTFLASH CARD 1
ACCESS
ACCESS
RUNCPU
RM
ACCESS
RUNCPU
2
MONITOR OUT
DATA LINK
CTRL
IN
DC POWER IN
T6.3A
T1.6A
1
87654321
2
AUDIO LINK
OUT
CPU OFF
1
8
9
16
CTRL
OUT
1
8
9
16
[Front panel detached]
[Rear]
[Front]
2
3
2
3
4
1
1
5
6 7
8
9
10
23
11
12
14
13
15
16
18
17
19
20
21
22
SYSTEM MANAGER VX-2000
• TheVX-2000SystemManageristhecentralmatrixsectionthatassignsinputsignalsto4audiobuses,and
controls the entire system.
• TheRemoteMicrophonesandothersoundsourcecomponentsareconnectedtotheinputmodulesmounted
in the VX-2000. The usable modules include the VX-200XR Remote Microphone Input Module, the VX-200XI
Audio Input Module (with Control Input), and the range of 900 Series modules (M-01F, M-01M, M-01P, M-01S,
M-01T, M-03P, M-51F, M-51S, M-51T, M-61F, M-61S, M-61T, U-01F, U-01P, U-01R, U-01S, U-01T, U-03R,
U-03S, U-61S, and U-61T).
• Upto2EV-200VoiceAnnouncementBoardscanbeinstalled.
• Equippedwithaninternalchimesource.
• 16externalcontrolinputsand16externalcontroloutputsareprovidedasstandardequipment.
