Chapter 3: SYSTEM OPERATION OUTLINE
8. BROADCAST PRIORITIES
3-15
RM-3
RM-4
Zone 1
Zone 2
Zone 3
[Broadcasts from RM-4 given higher priority than RM-3, or LIFO Broadcasts from both RM-3 and RM-4
of the same priority level]
RM-4 can broadcast to Zones 2 and 3 while RM-3 is broadcasting to Zones 1 and 2. The current broadcast is
terminated in Zone 1, and broadcasts from RM-4 are made in Zone 2 instead of RM-3 broadcasts.
• When all Emergency type Remote Microphones are one-to-one connected to each VX-200XR, they can
independently make broadcasts to their corresponding zones.
RM-200X RM-200X
(General) (General)
Zone C
RM-200XF
VX-200XR
Zone D
RM-200XF
VX-200XR
Zone B
(Emergency)
RM-200X
VX-200XR
RM-200X
(General)
Zone A
(Emergency)
RM-200X
VX-200XR
The RM-200X units of
General type are disabled
in Emergency mode.
To Next Page
