2-24 WorkCentre 3210/3220 Multifunction Printer Service Manual
Theory of Operation
Developing Voltage (DEV)
The Developing Voltage is supplied to the Developer Roller to transfer to the
toner to the charge on the OPC Drum scanned by the laser beam while
printing the image. The engine controls whether the high voltage is supplied
and its quantity.
■ Input voltage: 24 VDC ± 15%
■ Output voltage: -200 V ~ 600 V DC ± 3%
■ Output voltage fluctuation method: PWM control
■ Line regulation: under ± 3% (fluctuation input 21.6 V~27.6 V)
■ Load regulation: under ± 3%
■ Output voltage rising time: 50 ms Max
■ Output voltage falling time: 50 ms Max
■ Output Control Signal (BIAS-PWM): The CPU output is HV output when
PWM is low.
Supply
■ Output voltage: -300 V~800 VDC ± 50 V (ZENER using, DEV)
■ Line regulation: under ± 3% (fluctuation input 21.6 V~27.6 V)
■ Load regulation: under ± 3%
■ Output voltage rising time: 50 ms Max
■ Output voltage falling time: 50 ms Max
■ Output control signal (BIAS-PWM): The CPU is HV output when PWM is
Low.

Xerox WORKCENTRE 3210 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	Up to 24 ppm
Duplex Printing	Manual
Monthly Duty Cycle	Up to 30, 000 pages
Processor Speed	360 MHz
Memory	128 MB
Standard Paper Capacity	250 sheets
Scanner Type	Flatbed, ADF
Fax Transmission Speed	33.6 Kbps
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Folio, Legal, Letter
Scan Resolution	Up to 4800 x 4800 dpi
Maximum Paper Size	8.5 x 14 in (Legal)
Operating System Compatibility	Windows, Mac OS
Print Resolution	600 x 600 dpi
