Tank configuration data
ADM003GVAE1005 369
These parameters define the position of the top, middle, and bottom offsets for the respective pressure
transmitters in Hydrostatic/Hybrid calculations
MINIMUM LEVEL
This parameter defines the lowest level of which Hydrostatic Hybrid tank calculations can be performed
DENSITY DEADBAND
This parameter defines the minimum change in density that will cause the Hydrostatic/Hybrid tank calculation to
be executed
LOCAL GRAVITY
Enables the entry of the earth’s gravity in meters/sec
2
at the tank’s specific location used in Hydrostatic/Hybrid
calculations
ELEVATION
Defines the elevation above sea level at the tank’s specific location, used in Hydrostatic/Hybrid calculations
LATITUDE
Defines the Latitude (in deg, mins, sec) of the tank’s specific location, used in Hydrostatic/Hybrid calculations
LEVEL OFFSET
Defines the offset value to be applied to the level calculations as part of the Hydrostatic calculations
MAXIMUM FILL
This parameter defines the maximum safe level to which the tank can be filled (see Level Maximum Fill).
FuelsManager uses this value in the calculation of remaining and available volume(s). The maximum fill level
can be:
• User Defined - user can enter any value
• High - maximum fill level is the same as the high level alarm limi
• High-High - maximum fill level is the same as the high-high level alarm limit
Note! Selecting the 'User Defined' option also enables the Maximum Operating limit level alarm. This alarm
functions independently of the High and High-High alarms and is intended to give an additional stage of level
alarm monitoring
MINIMUM EMPTY
This parameter defines the minimum safe level to which the tank can be drained (see Level Minimum Empty).
FuelsManager uses this value in the calculation of remaining and available volume(s). The minimum empty level
can be:
• User Defined - user can enter any value.
• Low - minimum empty level is the same as the low level alarm limit
• Low-Low - minimum empty level is the same as the low-low level alarm limit
Note: Selecting the 'User Defined' option also enables the Minimum Operating limit level alarm. This alarm functions independently of the Low
and Low- alarms and is intended to give an additional stage of level alarm monitoring
