OPERATING THE TRANSCEIVER
THE CHANNEL SCREEN
ENVOY™ TRANSCEIVER REFERENCE MANUAL 29
Altitude,
Latitude/Northing,
Longitude/Easting, Speed
Derived from GPS signals from a GPS receiver
PA temperature Temperature of the heatsink
Tx power Monitored transmit power from the transceiver
Rx level Strength of an incoming signal shown in dBμV
Voltage Battery voltage
Last received call Who and when details of the last call received
SWR The ratio of forward to reflected power of the antenna during transmit
(typical range 1:1.0 to 1:1.8, which is only valid on the current channel)
Date, Time, Time Zone Current date, time and time zone of the control point
Package version, Package
build date
Details of the firmware in the control point and RFU ( )
Primary self address Self address of the first-listed HF network in your transceiver
Last received address Contact name or address of the last call received ( )
Last sent self address Self address of your transceiver that was sent with the last call that you
made ( )
Profile name Name of the TPS profile programmed into the transceiver
CP IP address, RFU IP
address
IP address of the control point ( ) or RFU ( )
Power down time Time at which the transceiver will power down, in 24-hour format (
Best LQA channel Future use
Crosspatch state Current crosspatch state may be Off ()|Active ()|Standby
()|Disconnected ()
Table 1: Information that may be shown in the status areas on the screen (cont.)
