5.2 SELECT: (Main) Menu
SELECT: Configuration Test Monitor
Info Store/Ld Utility ODU FAST ()
Figure 5-2 shows the hierarchal structure of the CDM-625 principle menu tree from the SELECT:
menu on down.
Press ENTER or CLEAR to immediately access the SELECT: menu screen from the opening screen.
From any nested menu, press CLEAR repeatedly until this screen reappears.
The table that follows identifies each menu branch available from the SELECT: menu and its
content section in this chapter. Functionality of each menu sub branch is further explained in
the subsequent chapter sections.
Configuration 5.2.1 Use to fully configure the modem.
Test 5.2.2
Use t o c onfigure t he m odem i nto one of several T est m odes, and t o
configure/monitor the BER Tester.
5.2.3
Use to monitor the current status of the modem and to view the log of stored
events for the modem.
Info 5.2.4
(Information) Use to view information on the modem without having to access
the Configuration screens.
(Store/Load) Use to store and retrieve up to 10 different modem configurations.
Utility 5.2.6
Use t o per form m iscellaneous functions – e.g., s etting t he Real-Time C lock,
adjusting the VFD brightness, etc.
ODU 5.2.7
Depending on 70/140 MHz or L-Band operation:
and c ontrol a standalone or r edundant Comtech EF D ata R F T ransceiver
(CSAT-5060 or KST-2000A/B) or LPOD BUC if connected.
See Appendix F. C DM-625 ODU (TRANSCEIVER, BUC, L NB) OPERATION
FAST 5.2.8
(Fully Accessible System Topology) Use to configure available options – e.g.,
extended dat a r ates, i nterfaces, et c. C ontact Comtech EF D ata C ustomer
Support for details.
The actual choices displayed in the submenus may vary according to which
FAST options have been activated and enabled. Where a FAST option affects a
menu, this is shown in the descriptive text.
From the top SELECT: menu, use the
◄ ►arrow keys to select from the choices shown, and then
press ENTER to continue.
