CDM-625 Advanced Satellite Modem Revision 13
Appendix F MN-CDM625
F–6
F.3.3.1 (SELECT: CONFIGURATION) Menu Branches
CONFIG: All Mode Tx Rx Clocks D&I/ACM
CnC EDMAC Misc Mask Remote IP ()
Use the
◄ ►arrow keys to select Tx, Rx, or Mask, and then press ENTER.
F.3.3.1.1 CONFIG: Tx Freq and CONFIG: Rx Freq Submenus
Tx-IF Frequency: 1750.0000 MHz
(LO:12500 MHz Sat:14250.0000 MHz) ()
Rx-IF Frequency: 1200.0000 MHz
(LO:12500 MHz Sat:13700.0000 MHz) ()
When you use the ODU menus to configure a BUC or LNB LO-frequency, the CONFIG: Tx→Freq
and CONFIG: Rx→Freq menu screens provide supplemental information on the bottom line. As
you edit the IF frequency, the Satellite frequency updates accordingly.
Satellite frequency = LO ± IF frequency
, where the ± sign is determined
by the LO mix setting:
• High-sided mix [–] (includes a spectral inversion);
• Low-sided mix [+].
To edit the Tx-IF or Rx Frequency, use the
◄ ►arrow keys to select a digit to edit, and then use
the
▲▼ arrow keys to change that digit. The available ranges are 50-180 MHz, and 950-2000
MHz (L-Band) (FAST option). The resolution is 100Hz. Press ENTER when done.
F.3.3.1.2 (SELECT: CONFIGURATION) Mask Submenus
The Mask submenus allow you to selectively mask (ignore) or make active various alarms and
traffic conditions that are monitored by the modem.
Alarm Masks: AIS Buffer Ref RxIF TxClk
TxSat RxSat Terr ROp BUC LNB CEX ()
Use the
◄ ►arrow keys to select BUC or LNB, and then press ENTER.
