E.3.3.1 Home > Modem > Interface
Open the Interface page from the Modem submenu. This page contains the following options:
Hot
Key
Dialog Window Option Entry
A Tx Interface Type
Typical for either entry – Use the ↑↓ arrow keys to select:
• RS-422
• V.35
• G.703 Balanced
C Rx Interface Type
•
G.703 Unbalanced
•
Audio
•
LVDS
•
HSSI
•
IP
•
ASI
•
IP ACM
B Tx Framing Mode
Typical for either entry – Use the ↑↓ arrow keys to select:
• Unframed • IBS • IDR
D Rx Framing Mode
•
DNI
•
EDMAC
•
DNI ++
•
ESC ++
•
EDMAC2
•
ODI
•
Frm QDI
•
EDMAC3
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Modem
submenu.
