CDM-625 Advanced Satellite Modem Revision 13

Ethernet-based Remote Product Management MN-CDM625

6–24

6.5.4.3 Configuration Pages

Use the ‘Configuration’ pages to configure all operating parameters for the CDM-625, including

its ODUs (Outdoor Units) when connected. Click the Modem, LAN, Routing, WAN, Overhead,

Utilities, D&I, BUC, or LNB tab to continue.

6.5.4.3.1 Configuration | Modem

Chapter 5. FRONT PANEL OPERATION

Use the ‘Configuration | Modem’ page to configure these modem operating parameters:

• Tx / Rx Interfaces and Framing* • Carrier-in-Carrier (CnC) Parameters

• Tx / Rx Operating Parameters • ACM Parameters

*The Tx / Rx Interface Types and Framing Modes have higher priority than other

parameters, and should be configured before setting other parameters.

Figure 6-13. Configuration | Modem page

Click [Submit] to save these settings.
