CDM-625 Advanced Satellite Modem Revision 13
Front Panel Operation MN-CDM625
5–50
5.2.1.12 CONFIG: Remote (Remote Control)
Remote Control=Local
(Local,Serial remote,Ethernet) ()
Use the
▲▼ arrow keys to select Local, Serial remote, or Ethernet, and then press ENTER.
If selecting Local, then reconfiguration via Serial Remote or Ethernet is not permitted although
remote monitoring is still possible. If Local or Serial Remote selected, a typical submenu is
displayed – proceed to the next section.
5.2.1.12.1 CONFIG: Remote  Local or Serial remote settings
Interface= RS-485-4W (232,485-2,485-4)
Address= 0001 9600 baud ()
If selecting either Local or Serial remote control, use the
◄ ► arrow keys to select Interface,
Address, or Baudrate; then, use the
▲▼ arrow keys to edit the Interface type, Baudrate, and
each digit of the Address. Note the following:
• Character format is not selectable and is fixed at 8-N-1.
• For RS-485 (aka EIA-485) – The permitted address range is from 0001 to 9999. Address
0000 is reserved for universal addressing.
• For RS-232 (aka EIA-232): The Address is fixed at 0000.
5.2.1.13 CONFIG: IP
IP Config: Addresses SNMP Setup
ANT AccessList PktP-Enable ()
Use the
◄ ►arrow keys to select Addresses, SNMP, Setup, ANT, AccessList, or – displayed only
when the optional IP Packet Processor card is installed – PktP-Enable, and then press ENTER.
5.2.1.13.1 CONFIG: IP  Addresses
IP Addresses: MAC Gateway
Addr/Range ()
Use the
◄ ►arrow keys to select MAC, Gateway, or Addr/Range, and then press ENTER.
