CDM-625 Advanced Satellite Modem Revision 13
Forward Error Correction Options MN-CDM625
7–10
7.7.3 End-to-End Processing Delay
In many cases, FEC methods that provide increased coding gain do so at the expense of
increased processing delay. However, with TPC, this increase in delay is very modest. Table 7-7
shows, for the CDM-625, the processing delays for the major FEC types, including the three TPC
modes.
Table 7-7. TPC/LDPC Processing Delay Comparison
FEC Mode (64 kbps data rate) End-to-end delay (ms)
Viterbi
Rate 1/2
9
Rate 1/2 + Reed Solomon
266
Sequential
Rate 1/2
74
Rate 1/2 + Reed Solomon
522
Turbo Product Coding
Rate 3/4
47
Rate 21/44
41
Rate 5/16
69
Rate 7/8
245 *
Rate 0.95
69
LDPC Coding
Rate 1/2 198
Rate 2/3, O/QPSK 234
Rate 2/3, 8-PSK, 8-QAM 350
Rate 3/4, O/QPSK 248
Rate 3/4, 8-PSK, 8-QAM, 16-QAM 395
*A larger block is used for the Rate 7/8 code, which increases decoding delay.
Note that, in all cases, the delay is inversely proportional to data rate, so for 128 kbps, the delay
values would be half of those shown above. It can be seen that the concatenated Reed-Solomon
cases increase the delay significantly (due mainly to interleaving/de-interleaving), while the TPC
cases yield delays which are less than or equal to Sequential.
Table 7-8. TPC/LDPC Summary
FOR
AGAINST
• Exceptionally good B ER per formance – significant improvement
compared with every other FEC method in use today.
Nothing!
• Most m odes hav e n o pr onounced t hreshold ef fect – fails
gracefully.
• Exceptional bandwidth efficiency.
• Coding gain independent of data rate (in this implementation).
•
Low decoding delay for TPC.
•
Easy field upgrade in CDM-625.
