E.3.8.2 Home > General Information > Modem Information

Open the Modem Information page from the General Information submenu. This page contains

the following option:

Hot

Key

Dialog Window Option Entry

A Circuit ID Enter an identifying label for the modem

Press the hot key to open the dialog window. Otherwise, press [ESC] to return to the General

Information submenu.
