E.3.5 Home > WAN Submenu
Open the WAN submenu from the Home menu. This submenu contains the following options:
Hot
Key
Configuration Page Function Sect.
A QoS Configure Quality of Service operation E.3.5.1
B
Compression
Configure Router Mode compression refresh rates
E.3.5.2
C Encryption
Configure Managed Switch Mode Encryption and define
Encryption Keys 1 through 8
E.3.5.3
Press a hot key to access a configuration page. See the specified appendix section for further
configuration options. Otherwise, press [ESC] to return to the Home menu.
E.3.5.1 Home > WAN > QoS Submenu
Open the QoS (Quality of Service) submenu from the WAN submenu. This submenu contains the
following options:
Hot
Key
Page / Dialog Window Description / Option Entry
A
QoS Max-Pri and Min-Max Table
See Sect. E.3.5.1.1
B
QoS Differentiated Services Table
See Sect. E.3.5.1.2
C
QoS SAR Feature
Use the ↑↓ arrow keys to select Disable or Enable
D
QoS Rules Delete All
Use the ↑↓ arrow keys to select No or Yes
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Network
submenu.
