E.3.6 Home > Outdoor Unit (ODU) Submenus (Summary Only)

1. After configuring the CDM-625 for 70/140 MHz operation, and then enabling

ODU Comms, you may use the Telnet CLI ‘ODU (Outdoor Unit)’ submenus

and pages to control and monitor a CSAT-5060 Outdoor Unit that is

connected via FSK to the CDM-625.

2. Comtech EF Data KST-2000A/B Transceivers and LPOD Outdoor Amplifiers /

Block Up Converters (BUCs) are not supported by the Telnet CLI at this time.

See Appendix F. CDM-625 ODU (TRANSCEIVER, BUC, LNB) OPERATION for

complete details about using this product-specific menu branch.
