E.3.2.4 Home > Administration > Reboot

Open the Reboot page from the Administration submenu. Use this page to perform a soft reboot

of the CDM-625. Otherwise, press [ESC] to return to the Administration submenu.

Hot

Key

Dialog Window Option Entry

A Force Reboot Use the ↑↓ arrow keys to select No (default) or Yes to reboot

You must restart your Telnet CLI session upon reboot of the CDM-625.
