CDM-625 Advanced Satellite Modem Revision 13
Ethernet-based Remote Product Management MN-CDM625
6–18
6.5.4.2.2 Admin | SNMP
• Chapter 5. FRONT PANEL OPERATION
• Sect. 6.3 SNMP INTERFACE
The Administrator must use this page to set and return administration information for the
CDM-625 SNMP (Simple Network Management Protocol) feature.
Figure 6-7. Admin | SNMP page
SNMP
• Simple Network Management – Use the drop-down list to select as Disabled or Enabled.
• Enable Authentication Trap – Use the drop-down list to select as Disable or Enable.
• Assign up to two SNMP Trap IP Addresses.
• Trap Version – Use the drop-down list to select SNMPv1 or SNMPv2.
• SNMP Read/Write/Trap Community Strings, SNMP Contact/Name/Location – Create or
edit these alphanumeric text strings as follows:
Setting Factory Default Typical Parameters
SNMP Read Community String public
The Read, Write, and Trap Community Strings
can be any alphanumeric combination with a
maximum length of 4 to 15 characters.
SNMP Write Community String
private
SNMP Trap Community String
comtech
SNMP Contact
N/A
The SNMP Contact, Name, and Location strings
can be any alphanumeric combination with a
maximum length of 0 to 20 characters.
SNMP Name
N/A
SNMP Location
N/A
Click [Submit Admin] to save these settings.
